spicekit: a small Rust SPICE reader

We’ve been chipping away at a small Rust library called spicekit, and it’s at a point where it’s worth showing off. It’s a pure-Rust reader for the SPICE kernel formats — the SPK ephemeris files, binary PCK rotation files, and supported text-kernel content that anyone doing solar-system dynamics ends up parsing. Originally it was just the guts of adam-core’s SPICE access path, lifted out into its own crate so we (and anyone else) can use it on its own.

It’s not a port of CSpice. The base crate doesn’t link CSpice and there’s no translated CSpice source in it — every executable line is written from the published NAIF file-format specs. Parity with CSpice is checked in a sibling crate, spicekit-bench, which links cspice-sys behind a feature flag and compares every numeric path and each supported text-kernel semantic against CSpice at machine-epsilon-scale tolerances. The only CSpice-derived artifact we ship is the body-name table (data, not code), and it’s reproduced under NAIF’s distribution terms.

What it covers

Kernel	Read	Write
DAF (shared SPK/PCK container)	yes	—
SPK Type 2 (Chebyshev, position-only)	yes	—
SPK Type 3 (Chebyshev, position + velocity)	yes	yes
SPK Type 9 (Lagrange, unequal time steps)	yes	yes
SPK Type 13 (Hermite, unequal time steps)	yes	—
Binary PCK (`pxform`, `sxform`, batch variants)	yes	—
Text kernels — body bindings, LSK `DELTET/*`, Earth→ITRF93 FK	yes	—
Built-in NAIF body table (`bodn2c` / `bodc2n`)	692 entries	—

That’s deliberately less than CSpice — we covered the operations adam-core actually issues, not the full surface. The text-kernel coverage is now a little broader than the first cut: custom NAIF_BODY_NAME / NAIF_BODY_CODE bindings, leapseconds-kernel DELTET/* values, and the narrow OBJECT_EARTH_FRAME = 'ITRF93' frame-kernel association used with binary Earth PCKs. Other text-kernel assignments are skipped by the parser on a best-effort basis, and furnsh-style loaders should reject otherwise-empty unsupported text kernels instead of silently dropping them. No async I/O, no CLI.

Using it from Python

pip install spicekit

import numpy as np
import spicekit

spk = spicekit.NaifSpk("/path/to/de440.bsp")

# Single state: Earth (399) wrt SSB (0) at J2000.
x, y, z, vx, vy, vz = spk.state(target=399, center=0, et=0.0)

# Batch over a week.
ets = np.linspace(0.0, 7 * 86_400.0, 1_000, dtype=np.float64)
states = spk.state_batch(target=399, center=0, ets=ets)  # (N, 6)

# PCK rotations.
pck = spicekit.NaifPck("/path/to/earth_latest_high_prec.bpc")
M = pck.sxform("J2000", "ITRF93", et=0.0)  # 6x6

# Body names.
spicekit.naif_bodn2c("EARTH")   # 399
spicekit.naif_bodc2n(399)       # "EARTH"

The shapes mirror the CSpice operations they replace, so swapping in for a spiceypy call site is mostly an import change.

Using it from Rust

use spicekit::{NaifFrame, SpkFile};

let spk = SpkFile::open("de440.bsp")?;
let state = spk.state(399, 0, 0.0, NaifFrame::J2000)?;
println!("{:?}", state); // [x, y, z, vx, vy, vz]

Memory-mapped, no FFI. There’s no kernel pool / furnsh aggregator in spicekit yet — each SpkFile is just an object you hold, and if you want CSpice-style “load these N files and dispatch by coverage” you build that on top. adam-core does exactly that in a small sibling crate; we’ll likely lift it down into spicekit once the API settles.

Benchmarks

The parity harness also measures latency on the same matched inputs. Speedup is cspice / spicekit. The latest table is substantially better than our early measurements; here is a representative slice from the current (0.2.2) BENCHMARKS.md:

op	case	n	cspice p50 (µs)	spicekit p50 (µs)	speedup
`spkez_batch`	sun wrt SSB, J2000	100	71.76	6.38	11.24x
`spkez_batch`	earth wrt sun, ecliptic	100	772.15	28.32	27.26x
`spkez_batch`	moon wrt earth, ITRF93	100	1802.21	61.42	29.34x
`sxform_batch`	ITRF93 → ECLIPJ2000	100	709.05	22.95	30.89x
`spkez_batch`	sun wrt SSB, J2000	10 000	7109.29	638.08	11.14x
`spkez_batch`	moon wrt earth, ITRF93	10 000	43 614.27	6123.54	7.12x
`sxform_batch`	ITRF93 → J2000	10 000	21 942.29	2323.51	9.44x
`lsk_dtpool`	`DELTET/*` metadata	50 000	12 417.64	15.46	803.31x
`lsk_gdpool`	`DELTET/*` values	50 000	25 715.63	2288.72	11.24x
`namfrm`	`ITRF93`	10 000	2817.19	275.01	10.24x

The broad pattern now is: 20–30x wins at moderate batch sizes on state and frame transforms, roughly 7–11x at 10k-element batches, and still ~2x on body-name lookup. The text-kernel numbers are especially large for metadata because supported LSK content is parsed into structured Rust data once, instead of repeatedly round-tripping through CSpice’s global kernel pool. These are single-threaded benchmark loops on the CI Linux x86_64 runner; the gains are batching, data layout, and FFI avoidance rather than hidden parallelism.

Things we like about it

Per-file readers. A NaifSpk is just an object you hold. CSpice’s full pool semantics — furnsh, last-loaded-wins, unload, dispatch across many files — aren’t in the base spicekit API yet. Supported text-kernel content is parsed, but the aggregate loader still lives in a small adam-core-side crate that wraps a Vec<spicekit reader> and does the dispatch. Once that API stabilizes we’ll likely move it into spicekit so callers don’t have to rebuild it.
Threaded reads work. Memory-mapped, no locks; Ray workers and Tokio tasks can share a reader without ceremony.
Smaller native footprint. No CSpice in the wheel.
The parity oracle is reusable. spicekit-bench is a fairly general “do these two SPICE implementations agree?” harness, which is handy any time we touch the numerics or supported text-kernel semantics.

Source, issues, and the full benchmark table: github.com/B612-Asteroid-Institute/spicekit. The crate is on crates.io and the Python package is on PyPI.
